| System Type |
16-bay Rackmount RAID system |
| Host Interface |
PCIe 3.0 |
| Data Transfer Rate |
32Gb/s |
| Disk Interface |
SAS / SATA × 16 |
| Disk Type |
3.5" / 2.5" / SSD |
| RAID Level |
0, 1, 5, 6, 0+1(10), JBOD |
| Cache Memory |
2GB DDR3 1866 with ECC-protected |
| JBOD Expansion |
JBOD × 3 |
| Operating Temperature |
0°C ~ 40°C |
| Storage Temperature |
-20°C ~ 70°C |
| Operating Humidity |
5% ~ 85%, Non-condensing |
| RAID Controller Functions |
- Online RAID Set Expansion and RAID Level Migration
- Online bad block data recovery and reallocation
- Online disk scrubbing with data refresh and parity
- Disk health monitoring by S.M.A.R.T
- Array Roaming and Drive Traveling
- Mirror Snapshot for fast backup and restore
- Disk Lag Proof Technology to guarantee disk timely response
- Equalization Mode to smooth sequential I/Os performance and reduce large fluctuation
|
| Management |
- Java-based RAIDGuard X GUI
- Event log saving in text file for quick troubleshooting
- Event notification by email (SMTP)
- LED indicator for RAID & disk drives status in front
- 400W (Single or Redundant), 110V~240V power supply
- Two 12cm × 12cm fans with Smart Fan Control feature
|
| Dimensions |
L: 567mm, W: 447mm, H: 131mm |
| Weight |
19.4kg |
